Rod mill

Direct deal Quality Assurance Quick response Service worry free

Rod mill

Production capacity:0.62-180t/h

Feed particle size:

Applicable materials:Pebbles, quartz sand, limestone, dolomite, granite, monazite, gold ore, iron ore, etc

客服 Do you need help? WhatsApp: 8613592531525

info@trifumac.com Hotline:+8613592531525

Rod millIntroduce

  A rod mill is a mill in which steel rods are loaded into the cylinder as the grinding body. Is our company adopts advanced controlled material in and out technology, combined with the actual grinding materials with appropriate grinding body, to the traditional surface contact to line contact, more uniform particle size, higher output, more reasonable price, widely used in metallurgy, chemical, glass, refractory and other industries on the uniformity of finished products after grinding requirements of high grinding operations. In recent years, it has also been used in the sand making industry for construction sand. Rod mill has dry and wet two forms, users can choose according to their actual needs.




Rod millAdvantage

  1. Uniform discharge particle size, wide range of application

  2. The discharge particle size can be adjusted

  3 .Small power, large capacity

  4. models to choose from


Rod millWorking Principle

  When working, the motor is driven by the reducer and the surrounding big gear or the low-speed synchronous motor is directly driven by the surrounding big gear to drive the cylinder to turn. The cylinder body is equipped with the appropriate grinding medium - steel rod. The grinding medium is raised to a certain height under the action of centrifugal force and friction force, and falls in the state of throwing or sliding. The ground material is continuously entered into the cylinder by the feed port, crushed by the moving grinding medium, and the product is discharged out of the machine by the overflow and the continuous feed force to carry out the next process operation.


Rod millApplication Scope

Rod millTechnical Parameter

Model

Diameter (mm)

Length (mm)

Cylinder speed (r/min)

Feed size (mm)

Discharge size (mm)

Yield (t))

Power (kw)

Rod load

GMB1835

φ1800

3500

22.8

≤25

≤5

20-50

160

13

GMB2136

φ2100

3600

20.9

≤25

≤5

30-70

210

18

GMB2145

φ2100

4500

20.9

≤25

≤5

50-80

250

20

GMB2436

φ2400

3600

19

20

≤5

60-120

280

21

GMB2736

φ2700

3600

17.5

20

≤5

100-220

400

24

GMB2745

φ2700

4500

17.5

20

≤5

120-250

500

27

GMB3245

φ3200

4500

16

20

≤5

300-450

800

50

GMB3645

φ3600

4500

15

20

≤5

430-580

1000

55
